Purposes
This productis suitablefor liquid and semi-fluid materialsinthefood,pharmaceuticaland chemicalindustries,such assoyproducts and dairy products,purified water,fruitjuice,edible oil,seasonings,laundry detergent,peanut butter,jam,chili sauce,porridge,yellow rice wine,vinegar,etc
Performance features
It is controlled by PLC.Parameters such as packaging volume and packagingspeed canall be set on the display screen,and the operation is simple.
Dualservo drive systemensures accurate metering.
Itcanautomatically complete bagloading,printing,bagopening,flling,sealing,shaping and output.
wesupportcustomized production accordingto non-standard specifications,andit can be equipped with an assembly line
technical parameters
|
Model |
HXL-F100 |
|
Bag length |
50-150mm |
|
Bag width |
25-120mm |
|
Bag capacity |
5-100ml |
|
Packaging speed |
30-50package/min |
|
Power supply |
220V/AC50Hz2.6Kw |
|
Air requirments |
1.8Mpa,600L/min |
|
Machine sive |
760*980*1700mm |
|
Machine weight |
380kg |
|
Packet style |
premade pouches |
